CF-1000 Crawler Dumper

The CF-1000 is purpose-built for palm oil plantations, offering a modern alternative to conventional practices involving wheelbarrows and live animals for fresh fruit bunch evacuation.
Equipped with rubber tracks, the CF-1000 is specifically designed to navigate through soft ground and peat conditions.

CF-1000 Rubber Crawler Dumper

The best solution for peat and soft ground conditions

The CF-1000 is purpose-built for palm oil plantations, offering a modern alternative to conventional practices involving wheelbarrows and live animals for fresh fruit bunch evacuation.
Equipped with rubber tracks, crafted from durable lightweight material and featuring ample ground clearance, the CF-1000 effortlessly navigates through challenging in-field terrain, making it well-suited for use on peat and soft ground conditions.
The robust rubber track effectively reduces soil compaction and damage on paths, and resists getting stuck, thanks to the low ground pressure.

Category: Product ID: 22920

Description

CF-1000 Crawler Dumper



More Advantages & Benefits of utilising the CF-1000 Rubber Crawler Dumper :
  • User-Friendly Operation and Minimal Maintenance: Operating the CF-1000 is straightforward, requiring minimal training, and its low maintenance design contributes to ease of use.
  • Enhanced Productivity through Efficient Crop Evacuation: The CF-1000 significantly boosts productivity by optimising the extraction of Fresh Fruit Bunches in Palm Oil plantations and transporting agriculture crops from the field.
  • Access to Challenging In-Field Terrains: The CF-1000 excels in traversing difficult in-field terrains such as peat soil, soft ground, narrow terraces, and areas with high rainfall.
  • Replacement of Labor-Intensive Techniques: The CF-1000 eliminates the need for labor-intensive methods like wheelbarrows, knapsacks, or the use of live animals, easing the overall workflow.
  • Soil-Friendly Rubber Track Technology: Equipped with rubber tracks, the CF-1000 minimises soil compaction and reduces path damage. Additionally, this feature lowers the risk of the CF-1000 getting stuck, contributing to operational reliability.

Specifications

Specification and Features
  • 7 hp heavy duty air-cooled diesel engine
  • 4 litre diesel tank capacity with average fuel consumption 0.30 litres/hr
  • Dual Heavy duty adjustable rubber track with hardened rollers
  • Payload: 500kg Unladen weight: 350kg
Dimensions
  • Length : 1905mm
  • Height : 977mm [over dumper]
  • Width : 1016mm [track to track]
  • Ground Clearance : 89mm

Product Video
